Machine tools
NTG-CKS2 50320
Grinding machines
- Swing (in) Φ20
- Swing (mm) Φ500
- Grinding wheel diameter (in) Φ37.4
- Grinding wheel diameter (mm) Φ950
- Grinding wheel width (in) 3.9
- Grinding wheel width (mm) 100
- Circumferential velocity (ft/s) 262.4
- Circumferential velocity (m/s) 80
Purchase options
Contact usDouble-head large crankshaft grinding machine for construction machinery, power generation, pumps, and marine applications.
High productivity large crankshaft grinding machine
- Double‑head large crankshaft grinding machine designed for construction machinery, power generation, pump, and marine applications.
- Engineered for high‑productivity machining of large crankshafts and heavy workpieces.
- Addresses large‑shaft challenges such as deformation, positioning accuracy, and environmental effects through advanced machine design.
- Komatsu NTC provides stable, reliable production backed by a long track record and extensive technical expertise.
- Ideal for manufacturers seeking consistent precision and durability in demanding large‑shaft grinding environments.
Resources
Features and benefits
High-precision positioning
The wheel head infeed uses NTC's unique hydrostatic slide and linear motor drive, combined with the NTC roundness correction system, to enable high-speed, high-precision profile grinding with reduced vibration.
High-reliability grinding wheel
The grinding wheel bearings utilize NTC's original hybrid hydro-static bearings with no metal contact, ensuring high rigidity, vibration suppression, and high stability.
Full automatic CNC workrest
All journals are automatically measured to prevent deformation of heavy shafts, and the CNC workrest is set to the optimal position. It can be adjusted to suit the characteristics of the shaft, improving operability and setup.
High productivity and user-friendly with double wheel head
Double wheel head enables flexible grinding such as simultaneous grinding of pins and journals. Besides, the automatic measurement function, correction system, and grinding status monitor support the operator.
Specifications
- Full specs
- Swing (in): Φ20
- Swing (mm): Φ500
- Grinding wheel diameter (in): Φ37.4
- Grinding wheel diameter (mm): Φ950
- Grinding wheel width (mm): 100
- Grinding wheel width (in): 3.9
- Control unit (maker): FANUC
- Machine size (W x D x H) (in): 551.2 x 255.9
- Machine size (W x D x H) (mm): 14,000 x 6,500
- Max workpiece length (in): 126
- Max workpiece weight (lbs): 1500
- Max workpiece weight (kg): 3307
- Grind wheel size (OD/width/ID) (in): Φ37.4/3.9/Φ2.0 (CBN wheel)
- Grind wheel size (OD/width/ID) (mm): Φ950/100/Φ50 (CBN wheel)
