Mining

Room and pillar

For the challenging industrial minerals and coal markets, where safety, productivity and low operating costs are paramount, Komatsu offers you a full range of entry development equipment, including heavy-duty continuous miners, continuous and batch haulage systems, and a wide range of feeder breakers.

Battery haulerBattery hauler(3) Battery scoopsBattery scoops(3) Continuous minersContinuous miners(8) Flexible conveyor trainFlexible conveyor train(1) Shuttle carsShuttle cars(2) Underground loaderUnderground loader(1)

BH10

Capacity 11.4 tonnes 12.5 tons
Entry width 355 cm 11 ft. 7 in
Minimum seam height 1.1 m 42 in

BH18

Capacity 16.4 tonnes 18 tons
Entry width 341 cm 12 ft. 4 in
Minimum seam height 1.45 m 57 in

BH20

Capacity 18.2 tonnes 20 tons
Entry width 362 cm 11 ft. 10 in
Minimum seam height 1.8 m 72 in

02ESV36

Seam height 91 - 160 cm 36 - 63 in
Bucket capacity 3 m^³ 120 ft.³
Maximum payload 14 970 kg 40,118 lbs.

02ESV56

Seam height 142 - 211 cm 56 - 83 in
Bucket capacity 3.43 m³ 121 ft.³
Maximum payload 27 590 kg 60,827 lbs.

02ESV60

Seam height 142 - 211 cm 56 - 83 in
Bucket capacity 4.35 m³ 153 ft.³
Maximum payload 27 590 kg 60,827 lbs.

12CM12

Maximum cutting height 3 685 - 4 600 mm 145 - 181 in
Minimum cutting height 1 400 - 2 150 mm 55 - 85 in
Total machine power
610 kW @ 60 Hz

545 kW @ 50 Hz

818 HP @ 60 Hz

730 HP @ 50 Hz

12CM15

Maximum cutting height 3 685 - 4 600 mm 145 - 181 in
Minimum cutting height 1 400 - 2 150 mm 55 - 85 in
Total machine power
610 kW @ 60 Hz

545 kW @ 50 Hz

818 HP @ 60 Hz

730 HP @ 50 Hz

12CM27

Maximum cutting height 3 685 - 5 000 mm
145 - 197 in
Minimum cutting height 1 600 - 2 500 mm 63 - 98 in
Total machine power 740 kW @ 950 V, 60 Hz
750 kW @ 2 300 V, 60 Hz
670 kW @ 950 V, 50 Hz
770 kW @ 3 300 V, 50 Hz
992 HP @ 950 V, 60 Hz

1,005 HP @ 2,300 V, 60 Hz

898 HP @ 950 V, 50 Hz

1,033 HP @ 3,300 V, 50 Hz

12HM series

Maximum cutting height 6 000 mm 236 in
Minimum cutting height 1 700 mm 67 in
Total machine power 730 - 1 251 kW 978 - 1678 HP

14CM09

Maximum cutting height 2 270 - 2 325 mm 89 - 91 in
Minimum cutting height 865 - 965 mm 34 - 38 in
Total machine power
630 kW @ 950 V, 60 Hz

695 kW @ 2 300 V, 60 Hz

884 HP @ 950 V, 60 Hz

931 HP @ 2,300 V, 60 Hz

14CM10

Maximum cutting height 3 099 mm 122 in
Minimum cutting height 965 mm 38 in
Total machine power 496 kW @ 950 V, 60 Hz 664 HP @ 950 V, 60 Hz

14CM15

Maximum cutting height 2 324 - 3 353 mm 91 - 132 in
Minimum cutting height 965 - 1 245 mm 38 - 49 in
Total machine power 600 kW @ 950 V, 60 Hz 804 HP @ 950 V, 60 Hz

14CM27

Maximum cutting height 3 400 mm 134 in
Minimum cutting height 1 000 mm 39 in
Total machine power
630 kW @ 950 V, 60 Hz

695 kW @ 2 300 V, 60 Hz

884 HP @ 950 V, 60 Hz

931 HP @ 2,300 V, 60 Hz

4FCT

Capacity 1 451 MTPH 1,600 TPH
Minimum seam height 140 - 224 cm 55 - 88 in
FCT tram speed 22 m/min 72 ft./min

10SC32

Rated load capacity 11 - 30 mt 12 - 33 st
Minimum seam height 135 - 264 cm 53 - 104 in
Conveyor horsepower 17 - 25 kW 23 - 34 HP

21SC04

Rated load capacity 8 mt 9 st
Minimum seam height 123.1 cm 48.5 in
Conveyor horsepower 1 @ 25 kW 1 @ 34 HP

14BU27

Tonnes per minute Up to 36.0 mt/min Up to 39.7 TPM
Seam height 106.7 cm 42 in
Weight base machine 31 615 kg 69,700 lbs.

Load more products

Let Komatsu help on the journey to autonomous transformation

Transforming your mining operation with autonomous solutions.

Learn more about our data solutions to help you increase productivity by optimizing automation

Komatsu soft rock advancements and automation

More technology, automation and innovation are coming to room and pillar and longwall mining to meet your increasing challenges.

Learn more about our soft rock solutions

Explore more videos

Crucial element to underground automation: Partnership

There’s more to successful automation in underground mining than just equipment and computers. A close partnership between the mine and manufacturer.

Automation: A Journey to underground improvement

Finding the right automation solution for an underground mine starts with understanding their goals. Through time studies and productivity models, specific challenges can be identified and targeted features can be applied to improve safety, productivity, and cost.

Total systems approach: Optimized high productivity mining system for future mine design

Learn how an optimized, total system approach to future mine design was developed for simultaneous cutting and bolting; eliminating haulage delays; decreasing bolting delays; reducing miner relocations; and increasing production of 1,900 tonnes per shift.

Underground soft rock mining industry

Stay on top of trends with help from our experts, customer success stories and industry point-of-view—so you feel equipped to successfully maintain and optimize your operation.

Learn more
