Tracked feller buncher

XT465L-5

  • Horsepower 247 kW @ 1 600 rpm 331 HP @ 1,600 rpm
  • Tractive effort 34 382 kgf 75,799 lbf.
  • Swing torque 79 100 Nm 58,341 lbs.-ft.

Your production partner

When you have big jobs to perform, the XT465L-5 tracked feller buncher will help you get them done – this machine is a powerhouse. It includes a heavy-duty four-way leveling system, 24% more lift capacity at full reach vs. the XT430-5/XT445L-5 models and can easily handle the Quadco 24” [61 cm] diameter high-speed disc saws.

  • Significantly greater lift capacity at full reach*
  • 10% more horsepower/16% more torque/5% lower fuel consumption*
  • Maximized uptime with optimized serviceability + Komtrax + Komatsu Care
  • *Compared to XT-3 models

Features and benefits

Track Feller Buncher_XT component_200729_DSC_5903.psd

Outstanding serviceability

Gull-wing engine hood folds down for easy access to all engine service points, and doubles as an elevated work platform. Four additional swing-out doors open wide to provide easy servicing of all key components. All major service points can be easily and quickly accessed.
Track Feller Buncher_XT430L-5_200729_XT430-5 with LogMax 7000XT Fixed Head IMG_9482.psd

Exceptional maneuverability and multifunctioning

Easily work through dense forests with a short-tail swing. Cut close to the tracks with the proven set-back boom design. Powerful swing torque for demanding applications. Closed-loop track drive with dedicated pumps allows simultaneous operation of travel, swing, boom and tools for increased productivity.
Tracked Feller Buncher_XT430_Ko_Just_Forest_2_2015_XT430-3 Anderson2_REV.psd

Increased lift capacity

Due to refined boom and arm geometry, significantly greater lift capacity is achieved at full reach vs. previous models. Plus, this machine has excellent balance between boom lift and arm holding capacity. Can be equipped with a wide selection of Quadco high-speed disc saws.
Track Feller Buncher_XT component_200729_20190122_135321.psd

Engineered modern forestry cab

Excellent comfort and visibility for total operator capability all day long. Positioned on the left side with superior visibility, especially of the tracks. Sloped roofline adds headroom for the operator. High-capacity automatic air conditioner, heater and defroster. Premium optional seat is ergonomic and heated/cooled.
Track Feller Buncher_XT component_200729_DSC_3825 as Smart Object 1.psd

Customizable operator controls

Advanced IQAN-MD4 digital control system enables customized control patterns and rates for up to three different operators. Helps to ensure precision and maximize multioperator productivity.
XT430L-3 Feller buncher - working.jpg

Rugged undercarriage

Using Komatsu engineering expertise, the tough and robust undercarriage provides significantly longer service life and day-to-day reliability.
Track Feller Buncher_XT component_200729_DSC_5821.psd

Powerful, fuel-efficient engine

Get more done with the powerful and efficient Cummins QSL9 engine. 10% more horsepower; 16% more torque; up to 5% lower fuel consumption compared to XT-3 models. EPA Tier 4 final emissions certified.
Track Feller Buncher_XT component_200729_DSC_5793.psd

Hydraulic protection

Robust forestry-specific guarding system covers the boom/arm/rear hydraulic tubes and hoses to help protect them from productivity-robbing operational hazards and debris.
Track Feller Buncher_XT_200729_20180308_114842.psd

Four-way leveling system

Heavy-duty four-way cab leveling system provides simultaneous front/rear/side leveling to ensure operator performance and safety on sloped terrain.
Oil Filter 6736-51-5142.jpg

Reduced hydraulic oil needs

Innovative new hydraulic tank system design requires 55% less hydraulic oil compared to the XT-3 models which lowers your maintenance costs.
KOMTRAX_back_Cover FIN flat.jpg

Standard Komtrax

Easily monitor vehicle usage insights that can boost productivity and aid in controlling cost with our standard telematics system. Monitors and records data such as location, operation map and fuel consumption. Notifies you when maintenance is due and helps keep your machine running at peak performance.
KO_KomatsuCare_Logo_2C_R2

Komatsu Care

Every new Komatsu XT-5 is covered by our Komatsu Care maintenance program, so you can keep your machine producing at its best. For the first three years or 2,000 hours (whichever occurs first) we take care of most regular service, inspection, filter and fluid replacement, and labor – at your location, and using only genuine Komatsu fluids and filters.

Specifications for XT465L-5

Close all Expand all
US system Metric
Engine
Model
Cummins QSL9 diesel engine
Type Watercooled, 4-cycle, direct injection
Aspiration VGT™ Turbocharger, infinitely adjustable with electronic controls.
High pressure fuel injection, in cylinder advanced combustion technology, cooled EGR.
Number of cylinders Inline In-line, 6-cylinder
Bore
114 mm
Stroke
135 mm
Piston displacement
9 L 543 in3
Horsepower:

Peak
247 kW @ 1 600 rpm
Rated
224 kW @ 2 000 working rpm
Peak Torque
1 573 Nm @ 1 600 rpm
Fan Drive Type
Hydraulic

*Complies with U.S. EPA Tier 4 Final emissions standard

Model
Cummins QSL9 diesel engine
Type Watercooled, 4-cycle, direct injection
Aspiration VGT™ Turbocharger, infinitely adjustable with electronic controls.
High pressure fuel injection, in cylinder advanced combustion technology, cooled EGR.
Number of cylinders Inline In-line, 6-cylinder
Bore
4.49 in
Stroke
5.69 in
Piston displacement
9L 543 in3
Horsepower:

Peak
331 HP @ 1,600 rpm
Rated
300 HP @ 2,000 working rpm
Peak Torque
1,160 lbs.-ft. @ 1,600 rpm
Fan Drive Type
Hydraulic

*Complies with U.S. EPA Tier 4 Final emissions standard

Electrical System
Type
24 V with master disconnect
Alternator 24 V, 100A
Work Lights 11 LED
Type
24 V with master disconnect
Alternator 24 V, 100A
Work Lights 11 LED
Hydraulics
Implement pump  Variable displacement piston, Max Flow 324 L/min
Attachment pump
Variable displacement piston, Max Flow 200 L/min
Saw pump
Variable displacement piston, Max Flow 143 L/min
Track drive pump
2x Variable displacement piston, Max Flow 167 L/min
Fan pump
2x Gear, Max Flow 44 L/min
Charge pump
2x Gear, Max Flow 95 L/min
Travel motor
Variable displacement piston
Swing motor
Fixed displacement bent axis piston
Cooling
Independent Radiator/CAC/ Hydraulic oil coolers with thermostatically controlled fans
Implement pump  Variable displacement piston, Max Flow 86 gpm
Attachment pump
Variable displacement piston, Max Flow 53 gpm
Saw pump
Variable displacement piston, Max Flow 38 gpm
Track drive pump
2x Variable displacement piston, Max Flow 44 gpm
Fan pump
2x Gear, Max Flow 11 gpm
Charge pump
2x Gear, Max Flow 25 gpm
Travel motor
Variable displacement piston
Swing motor
Fixed displacement bent axis piston
Cooling
Independent Radiator/CAC/ Hydraulic oil coolers with thermostatically controlled fans
Drive and Brakes
Drive Method
Hydrostatic, independent closed loop
Steering control
Foot Pedals
Max travel speed

High
4.6 kph
Low
2.1 kph
Max tractive effort
34 382 kgf
Service brake
Hydraulic
Parking brake
Hydraulic

Drive Method
Hydrostatic, independent closed loop
Steering control
Foot Pedals
Max travel speed

High
2.9 mph
Low
1.3 mph
Max tractive effort
75,799 lbf.
Service brake
Hydraulic
Parking brake
Hydraulic

Leveling System
Type 2-cylinder,
4-way heavy duty
Leveling angle

Front
25° / 47%
Rear
6° / 11%
Side/Side
18° / 32%
Type 2-cylinder,
4-way heavy duty
Leveling angle

Front
25° / 47%
Rear
6° / 11%
Side/Side
18° / 32%

Swing System
Rotation Continuous rotation
Bearing

Heavy duty, 37-bolt
Double row bearing

Drive method Hydrostatic
Swing speed 0 to 7.0 rpm
Swing torque 79 100 Nm
Swing brake Dynamic
Parking brake Hydraulic
Rotation Continuous rotation
Bearing

Heavy duty, 37-bolt
Double row bearing

Drive method Hydrostatic
Swing speed 0 to 7.0 rpm
Swing torque 58,341 lbs.-ft.
Swing brake Dynamic
Parking brake Hydraulic
Undercarriage
Carbody HD boxed frame structure with flat bottom and storage trunk
Track frame
Boxsection, bolted
Track type Grease sealed
Number of shoes/links 47 per side
Track rollers 9 per side
Bushings & rollers Heavy duty
Track pitch 216 mm
Carbody HD boxed frame structure with flat bottom and storage trunk
Track frame
Boxsection, bolted
Track type Grease sealed
Number of shoes/links 47 per side
Track rollers 9 per side
Bushings & rollers Heavy duty
Track pitch 8.5 in
Boom Performance
Lifting capacity* @ 1.5 m pin height (less attachment)

@ 3.0 m
14,200 kg
@ 4.6 m
9,760 kg
@ 6.0 m 5,940 kg
@ Full Reach
5,590 kg

* Feller buncher boom and arm, designed for 20-22" in high speed disc saws.

Lifting capacity* @ 5' pin height (less attachment)

@ 10'
31,398 lbs.
@ 15'
21,519 lbs.
@ 20'
13,098 lbs.
@ Full Reach
12,326 lbs.

* Feller buncher boom and arm, designed for 20-22" in high speed disc saws.

Coolant & Lubricant Capacity (Refilling)
Fuel tank 526 L
Cooling system 35.7 L
Engine oil pan 18.9 L
Final drive per side 11 L
Swing gear box 4.3 L
Hydraulic tank
216 L
DEF
56.8 L
Gear box (PTO)
6.2 L
Hood tilt
4.5 L
Fuel tank 140 US gal
Cooling system 9.43 US gal
Engine oil pan 4.99 US gal
Final drive per side 2.91 US gal
Swing gear box 1.14 US gal
Hydraulic tank
57 US gal
DEF
15 US gal
Gear box (PTO)
1.63 US gal
Hood tilt
1.19 US gal

Operating Weight (less attachment)
Track shoes 600 mm
Operating weight* 33 800 kg
Ground pressure 66.8 kPa

*Operating weight includes feller buncher boom, feller buncher arm, 1/2 tank of fuel, rated capacity of lubricants, coolant, operator and standard equipment.


Track shoes SG 24 in
Operating weight* 74,516 lbs.
Ground pressure 9.7 psi

*Operating weight includes feller buncher boom, feller buncher arm, 1/2 tank of fuel, rated capacity of lubricants, coolant, operator and standard equipment.


  • Alternator, 100 ampere, 24V
  • Air cleaner, dry type with air intake pre-cleaner
  • Auto-idle shutdown system
  • Automatic air conditioner, heater & defroster with pressurization and 6 adjustable vents
  • Batteries, 2 x 12V, 1000 AH
  • Cab, ROPS/OPS/FOPS/TOPS/FOG/WCB/Oregon OSHA certified forestry:
    —2 x 12V power outlets
    —Cellphone holder
    —Coat hook, magnetic and moveable base
    —Cupholder, fold-down/up
    —Literature box with cover
    —Lockable door
    —Insulated drink bottle & lunch box cooler
    —Ventilation fan
  • Carbody, wide gauge with storage trunk
  • Continuous swing rotation
  • Control handles, Sure Grip
  • Cooling:
    —Engine temperature-sensing auto-reversing fan
    —Hydraulic oil cooler temperature-sensing auto-reversing fan
    —Charge air cooler temperature-sensing auto-reversing fan
  • Electrical system master disconnect switch
  • Electrical joystick/foot pedal controls
  • Emergency escapes, 3 (front window, side door and roof hatch)
  • Engine, Cummins QSL9, 9 Liter, 331 HP Peak @ 1600 rpm
  • Engine compartment service light
  • Engine interface monitoring system
  • Final drives, Komatsu with spring-applied oil released track brakes
  • Fire extinguisher, 10 lb. handheld
  • Fuel water separator
  • Heater, charge oil relief
  • Horn, electric
  • Hydraulic system, load sensing
  • Hydraulic tank oil refill pump, 24V
  • Hydraulic tank vacuum pump
  • Instrument panel with switches, dials, LED warning lights, and engine stop button
  • IQANMD4 Digital Control System with 7” LED color touch screen display
  • KOMTRAX monitoring system
  • Leveling, 4way HD cab leveling (XT445L5/XT465L5)
  • Light, interior dome LED
  • Muffler with blanket
  • Operator Identification System
  •  Premium seat, vented and heated
  • Pumps:
    —Attachment, 1 x VDPP, 200 ltr/min
    —Implement, 1 x VDPP, 324 ltr/min
    —Saw drive, 1 x VDPP, 143 ltr/min
    —Track drive, 2 x VDPP, 167 ltr/min each
    —Fan, 2 x Gear, 44 ltr/min each
    —Charge, 1 x Gear, 95 ltr/min
  • Radio AM/FM Weather Band stereo with iPod/MP3 input jack
  • Rear view monitoring system (1 camera)
  • Rubber debris skirt
  • Seat, adjustable high back suspension
  • Seat belt, 3" retractable
  • Swing bearing, HD 22bolt single row (XT4305/XT445L5)
  • Swing bearing HD 37bolt double row (XT465L5)
  • Swing motor, 56cc
  • Track adjusters, hydraulic
  • Track chain, grease sealed Komatsu 216 mm pitch
  • Track drive, closed loop
  • Track motors, 2-speed VDPP auto-shift with variable speed control
  • Track rollers
  • Track shoes, 600 mm single grouser
  • Track sliders
  • Travel alarm
  • Travel pedals
  • Windows, polycarbonate
    —Front & skylight windows, 32 mm
    —Left, right & rear windows, 13 mm
  • Work lights, 11 LED type
  • Alternator, 100 ampere, 24V
  • Air cleaner, dry type with air intake pre-cleaner
  • Auto-idle shutdown system
  • Automatic air conditioner, heater & defroster with pressurization and 6 adjustable vents
  • Batteries, 2 x 12V, 1000 AH
  • Cab, ROPS/OPS/FOPS/TOPS/FOG/WCB/Oregon OSHA certified forestry:
    —2 x 12V power outlets
    —Cellphone holder
    —Coat hook, magnetic and moveable base
    —Cupholder, fold-down/up
    —Literature box with cover
    —Lockable door
    —Insulated drink bottle & lunch box cooler
    —Ventilation fan
  • Carbody, wide gauge with storage trunk
  • Continuous swing rotation
  • Control handles, Sure Grip
  • Cooling:
    —Engine temperature-sensing auto-reversing fan
    —Hydraulic oil cooler temperature-sensing auto-reversing fan
    —Charge air cooler temperature-sensing auto-reversing fan
  • Electrical system master disconnect switch
  • Electrical joystick/foot pedal controls
  • Emergency escapes, 3 (front window, side door and roof hatch)
  • Engine, Cummins QSL9, 9 Liter, 331 HP Peak @ 1600 rpm
  • Engine compartment service light
  • Engine interface monitoring system
  • Final drives, Komatsu with spring-applied oil released track brakes
  • Fire extinguisher, 10 lb. handheld
  • Fuel water separator
  • Heater, charge oil relief
  • Horn, electric
  • Hydraulic system, load sensing
  • Hydraulic tank oil refill pump, 24V
  • Hydraulic tank vacuum pump
  • Instrument panel with switches, dials, LED warning lights, and engine stop button
  • IQANMD4 Digital Control System with 7” LED color touch screen display
  • KOMTRAX monitoring system
  • Leveling, 4way HD cab leveling (XT445L5/XT465L5)
  • Light, interior dome LED
  • Muffler with blanket
  • Operator Identification System
  •  Premium seat, vented and heated
  • Pumps:
    —Attachment, 1 x VDPP, 53 gpm
    —Implement, 1 x VDPP, 86 gpm
    —Saw drive, 1 x VDPP, 38 gpm
    —Track drive, 2 x VDPP, 44 gpm each
    —Fan, 2 x Gear, 11 gpm each
    —Charge, 1 x Gear, 25 gpm
  • Radio AM/FM Weather Band stereo with iPod/MP3 input jack
  • Rear view monitoring system (1 camera)
  • Rubber debris skirt
  • Seat, adjustable high back suspension
  • Seat belt, 3" retractable
  • Swing bearing, HD 22bolt single row (XT4305/XT445L5)
  • Swing bearing HD 37bolt double row (XT465L5)
  • Swing motor, 56cc
  • Track adjusters, hydraulic
  • Track chain, grease sealed Komatsu 8.5" pitch
  • Track drive, closed loop
  • Track motors, 2-speed VDPP auto-shift with variable speed control
  • Track rollers
  • Track shoes, 24" single grouser
  • Track sliders
  • Travel alarm
  • Travel pedals
  • Windows, polycarbonate
    —Front & skylight windows,1.25"
    —Left, right & rear windows, 0.5"
  • Work lights, 11 LED type
  • Arms
    —Feller buncher, 3960 mm straight with tree deflector
  • Booms
    —Feller buncher 4530 mm
  • Carrier rollers
  • Fire suppression system, automatic liquid chemical
  • Heater, fuel-fired jacket water and hydraulic oil preheater
  • Hydraulic systems
    —Disc saw
    —Bar saw, Intermittent disc saw, Combination disc/bar saw
  • Oil cooler, pump drive
  •  Side view camera
  • Track shoes
    —700 mm single grouser
    —700 mm double grouser (XT4305)
  • Uptime spare parts kits
    —Base machine
    —Engine filters
  • Arms
  • - Tracker feller buncher: 13' straight with tree deflector

  • Booms
  • - Feller buncher: 14'' 10"

  • Carrier rollers
  • - Counterweight (rear): XT430-5: 2,645

  • Fire suppression system, automatic liquid chemical
  • Heater, fuel-fired jacket water and hydraulic oil pre-heater
  • Hydraulic systems
  • - Bar saw, intermittent disc saw, combination disc/bar saw
    - Disc saw
    - Harvesting saw (XT430/XT445L-5)
    - Mulcher

  • Oil cooler, pump drive
  • Side camera (right)
  • Track shoes
  • - 28-inch single grouser
    - 28-inch double grouser (XT430-5/XT445L-5)

  • Uptime spare parts kits
  • - Base machine
    - Engine filters

Support you can count on

Find what works for you
