Large wheel loader

WA475-10

  • Horsepower 216 kW @ 1 600 rpm 290 HP @ 1,600 rpm
  • Operating weight 25 510 - 27 397 kg 56,240 - 60,400 lbs.
  • Bucket capacity 4.2 - 4.6 m³ 5.5 - 6.0 yd³

Designed for our most demanding customer: You

The newly designed WA475-10 features next-generation technology developed with input from customers like you to deliver improved productivity and lower fuel costs. Ideal for quarry, waste, infrastructure, forestry, and non-residential construction applications.

  • Up to 30% more fuel efficient*
  • 8% more breakout force*
  • 20% more boom lift force*
  • * compared to the prior model

Features and benefits

WA 475 KHMT_2.jpg

Fuel efficient yet powerful

Dual-mode engine power selector offers two operating modes: economy and power. The innovative Komatsu Hydraulic Mechanical Transmission (KHMT) improves fuel economy by up to 30% versus the prior model while providing 18 more horsepower.
Wheel Loader_WA475-10_Denver CO_DB_200206_KMCG-020620_324.psd

Simplified, fuel-saving controls

Independent work equipment control separates the accelerator pedal from the speed of the work equipment. Your operators operate the bucket with levers only for greater control, and can approach trucks with no brake dragging, thus improving fuel economy.
Wheel Loader_WA475-10_Cartersville GA_JQ_200608_3K1A2943.psd

Steering choices for operators

Choose a standard steering wheel or the new optional Advanced Joystick Steering System (AJSS), designed to minimize operator fatigue. AJSS provides precise wrist and finger steering and control, even during full speed travel.
Wheel loader_FBmultifunctionloadermeter_WA470-10_load_meter_CKedit.psd

Multi-function load meter

Measure the weight in the bucket by simply pressing a switch. Dump monitoring allows for real-time monitoring of the weight of any material in the bucket after dumping. Empty bucket calibration can be done anytime to ensure accuracy.
Wheel Loader_WA475 10_literature link_b01_e.eps

Bucket engineered for productivity

A redesigned bucket focused on boosting productivity. Generous curves on the side wall better retain material, and a wrap angle enhances pile penetration to make the bucket easy to fill. Material retention has been improved in load and carry operations.
Wheel Loader_WA475 10_literature link_YL_Cab_wide_v1.psd

Cab blends comfort and utility

A redesigned cab for a spacious, ergonomic comfortable environment. Additional glass in key areas improves visibility. Frequently used switches are at eye level, allowing operators to stay focused on the work environment.
Wheel Loader_WA475-10_Cartersville GA_JQ_200608_3K1A2920.psd

Comfortable seat helps fight fatigue

A more comfortable ride to reduce fatigue over long shifts with a new air suspension seat that enhances support on rough roads and dampens machine vibrations. Optional Multi-Function Monolever is also available.
Wheel Loader_WA475-10_Cartersville GA_JQ_200608_3K1A3148.psd

Fast recall of boom positions

Designed for convenience and efficiency, boom positions are adjustable in the cab with the push of a button. The bucket positioner can memorize three horizontal settings so the operator can easily change attachments without having to reset the bucket position.
Wheel Loader_WA475-10_Cartersvile GA_DS_190925_KOM_1246.jpg

Monitor system offers full rear view

An exceptional view behind the machine with a full color monitor placed at eye level in the cab. The monitor can be set “always on” or only when the loader goes into reverse. Visual reference guidelines offer an additional safeguard.
Wheel Loader_WA475-10_Cartersville GA_JQ_200608_3K1A2927.psd

Less fuel lost when idling

Save fuel by reducing idle time with the Komatsu Auto Idle Shutdown. It shuts the engine off and applies the parking brake and hydraulic lock after a preset idle time limit.
Wheel Loader_WA475-10_Yard Loader_Cartersville GA_JQ_200608_3K1A2488.psd

Full front and rear fenders

Full access to the engine compartment with standard full front and rear fenders that raise when the engine hood is opened. Front fenders are equipped with an extension that minimizes debris strike when operating in reverse.
Wheel Loader_WA475-10_Cartersville GA_JQ_200608_3K1A3033.psd

Electronic tilting engine hood

Easy access and service with a one-piece engine hood that can quickly be opened with a switch located on the left side of the machine near the battery box. Two side doors allow easy access for daily checks.

Specifications for WA475-10

Close all Expand all
US system Metric
Engine
Model Komatsu SAA6D125E-7*
Type Water-cooled, 4-cycle
Aspiration Turbo-charged, after-cooled, cooled EGR
Number of cylinders 6
Bore x stroke 125 x 150 mm
Piston displacement 11.04 L
Governor all-speed, electronic
Horsepower:
    SAE J1995 - Gross 217 kW
    ISO 9249/SAE J1349 - Net 216 kW
    Net horsepower at the maximum
    speed of radiator cooling fan is
208 kW 279 HP
    Rated rpm 1 600 rpm
Fan drive method for radiator cooling Hydraulic
Fuel system Direct injection
Lubrication system:
    Method Gear pump, force-lubrication
    Filter Full-flow type
Air cleaner Dry type with double elements and dust evacuator, plus dust indicator

*EPA Tier 4 Final emissions certified

Model Komatsu SAA6D125E-7*
Type Water-cooled, 4-cycle
Aspiration Turbo-charged, after-cooled, cooled EGR
Number of cylinders 6
Bore x stroke 4.9 x 5.9 in
Piston displacement 674 in³
Governor all-speed, electronic
Horsepower:
    SAE J1995 - Gross 291 HP
    ISO 9249/SAE J1349 - Net 290 HP
    Net horsepower at the maximum
    speed of radiator cooling fan is
279 HP
    Rated rpm 1,600 rpm
Fan drive method for radiator cooling Hydraulic
Fuel system Direct injection
Lubrication system:
    Method Gear pump, force-lubrication
    Filter Full-flow type
Air cleaner Dry type with double elements and dust evacuator, plus dust indicator

*EPA Tier 4 Final emissions certified

Transmission
Transmission Hydraulic Mechanical planetary type
Travel speed:
(Measured with 26.5-25 tires)

    Forward 3.0 - 38.0 kph
    Reverse 3.0 - 28.0 kph
Transmission Hydraulic Mechanical planetary type
Travel speed:
(Measured with 26.5-25 tires)

    Forward 1.9 - 23.6 mph
    Reverse 1.9 - 17.4 mph
Axles and Final Drives
Drive system
Four-wheel drive
Front
Fixed, semi-floating
Rear
Center-pin support, semi-floating, 26° total oscillation
Reduction gear
Spiral bevel gear
Differential gear
Conventional type
Final reduction gear
Planetary gear, single reduction
Drive system
Four-wheel drive
Front
Fixed, semi-floating
Rear
Center-pin support, semi-floating, 26° total oscillation
Reduction gear
Spiral bevel gear
Differential gear
Conventional type
Final reduction gear
Planetary gear, single reduction
Brakes
Service brakes Hydraulically actuated, wet multiple-disc brakes actuate on four wheels
Parking brake Wet multiple-disc brake
Secondary brake One of dual service brake circuits is commonly used
Service brakes Hydraulically actuated, wet multiple-disc brakes actuate on four wheels
Parking brake Wet multiple-disc brake
Secondary brake One of dual service brake circuits is commonly used
Steering System
Type Articulated type, full-hydraulic power steering
Steering angle 35° each direction (40° to max end stop)
Minimum turning radius at the center of outside tire 6 630 mm
Type Articulated type, full-hydraulic power steering
Steering angle 35° each direction (40° to max end stop)
Minimum turning radius at the center of outside tire 21 ft. 9 in
Hydraulic System
Steering system:
Hydraulic pump Piston pump
Capacity 195 L/min
Relief valve setting 24.5 MPa / 250 kgf/cm²
Hydraulic cylinders:
Type Double-acting, piston type
Number of cylinders 2
Bore x stroke 95 x 441 mm
Loader control:
Hydraulic pump Piston pump
Capacity 333 L/min
Relief valve setting 34.3 MPa / 350 kgf/cm²
Hydraulic cylinders:
Type Double-acting, piston type
Number of cylinders—bore x stroke:
Lift cylinder / 2 150 x 764 mm
Bucket cylinder / 1 180 x 540 mm
Control valve 2-spool type
Control positions:
Boom Raise, hold, lower, and float
Bucket Tilt-back, hold, and dump
Hydraulic cycle time (rated load in bucket)
Raise 5.8 s
Dump 1.8 s
Lower (Empty) 3.1 s
Steering system:
Hydraulic pump Piston pump
Capacity 51.5 US gpm
Relief valve setting 3,555 psi
Hydraulic cylinders:
Type Double-acting, piston type
Number of cylinders 2
Bore x stroke 3.7 x 17.4 in
Loader control:
Hydraulic pump Piston pump
Capacity 88.0 US gpm
Relief valve setting 4,980 psi
Hydraulic cylinders:
Type Double-acting, piston type
Number of cylinders—bore x stroke:
Lift cylinder / 2 5.9 x 30.0 in
Bucket cylinder / 1 7.0 x 21.2 in
Control valve 2-spool type
Control positions:
Boom Raise, hold, lower, and float
Bucket Tilt-back, hold, and dump
Hydraulic cycle time (rated load in bucket)
Raise 5.8 s
Dump 1.8 s
Lower (Empty) 3.1 s
Service Refill Capacities
Cooling system 65 L
Fuel tank 380 L
Engine 38 L
Hydraulic system 135 L
Axle front 59 L
Axle rear 59 L
Transfer case 40 L
DEF tank 36 L
Cooling system 17.1 US gal
Fuel tank 100.3 US gal
Engine 10.0 US gal
Hydraulic system 35.7 US gal
Axle front 15.6 US gal
Axle rear 15.6 US gal
Transfer case 10.6 US gal
DEF tank 9.5 US gal
  • 2-spool valve for boom and bucket control
  • Alternator, 140 A
  • Anchorage points
  • Automatic hydraulic-driven fan with automatic reverse rotation
  • Back-up alarm
  • Batteries, 140 Ah/12V (2), 930 CCA
  • Battery disconnect
  • Boom Kick-out, in-cab adjustable
  • Bucket Positioner, in-cab adjustable, 3 positions
  • Color rear view camera and monitor
  • Counterweight, standard and additional
  • Electronically Controlled Suspension System (ECSS)
  • Engine, Komatsu SAA6D125E-7 diesel
  • Engine shut-off system, electric
  • EPC fingertip controls with F-N-R switch, two levers
  • Equipment Management Monitoring System (EMMS)
    - Lights (central warning, brake oil pressure, engine oil pressure, parking brake, cooling fan reverse, KDPF restriction, seat belt caution, Komtrax message)
    - Gauges (Engine water temperature, ecology, fuel level, DEF level, hydraulic oil temperature, speedometer/tachometer)
  • Front fenders with extensions
  • Fuel pre-filter with water separator
  • Heated and power adjustable rear view mirrors, outside (2) inside (2)
  • Horn, electric
  • Komatsu SmartLoader Logic
  • Komatsu Auto Idle Shutdown
  • KOMTRAX® Level 5
  • Lift cylinders and bucket cylinder
  • Lights
    - Back-up light, LED
    - Stop and tail light, LED
    - Turn signal lamps, 2 front and 2 rear with hazard switch
    - Working lights, LED, 2 front cab mount
    - Working lights, LED, 2 front fender mount
    - Working lights, LED, 2 rear grill mount
  • Loader linkage with standard lift arm
  • Parking brake, electric
  • Radiator, wider core
  • Radiator mask, swing out
  • Rear full fenders
  • Rims for 26.5-25 tires
  • ROPS/FOPS Cab Level 2
    - 2 x DC12V electrical outlets
    - Ashtray
    - Auto air conditioner
    - Cigarette lighter, 24V
    - Color LCD/TFT multi-monitor
    - Cup holder
    - Floor mat
    - Operator seat, reclining, air suspension type, heated
    - Radio, AM/FM with AUX input jack
    - Rear defroster, electric
    - Seatbelt, 2-point retractable, 76 mm width
    - Space for Lunch box
    - Steering wheel, tilt and telescopic
    - Sun visor, front window
    - Windshield washer and wiper, front with intermittent
    - Windshield washer and wiper, rear
  • Service brakes, wet disc type
  • Starting motor, 7.5 kW
  • Transmission KHMT infinitely variable with 4 forward/reverse virtual gear settings
  • Vandalism protection kit, padlocks for battery box (2)
  • 2-spool valve for boom and bucket control
  • Alternator, 140 A
  • Anchorage points
  • Automatic hydraulic-driven fan with automatic reverse rotation
  • Back-up alarm
  • Batteries, 140 Ah/12V (2), 930 CCA
  • Battery disconnect
  • Boom Kick-out, in-cab adjustable
  • Bucket Positioner, in-cab adjustable, 3 positions
  • Color rear view camera and monitor
  • Counterweight, standard and additional
  • Electronically Controlled Suspension System (ECSS)
  • Engine, Komatsu SAA6D125E-7 diesel
  • Engine shut-off system, electric
  • EPC fingertip controls with F-N-R switch, two levers
  • Equipment Management Monitoring System (EMMS)
    - Lights (central warning, brake oil pressure, engine oil pressure, parking brake, cooling fan reverse, KDPF restriction, seat belt caution, Komtrax message)
    - Gauges (Engine water temperature, ecology, fuel level, DEF level, hydraulic oil temperature, speedometer/tachometer)
  • Front fenders with extensions
  • Fuel pre-filter with water separator
  • Heated and power adjustable rear view mirrors, outside (2) inside (2)
  • Horn, electric
  • Komatsu SmartLoader Logic
  • Komatsu Auto Idle Shutdown
  • KOMTRAX® Level 5
  • Lift cylinders and bucket cylinder
  • Lights
    - Back-up light, LED
    - Stop and tail light, LED
    - Turn signal lamps, 2 front and 2 rear with hazard switch
    - Working lights, LED, 2 front cab mount
    - Working lights, LED, 2 front fender mount
    - Working lights, LED, 2 rear grill mount
  • Loader linkage with standard lift arm
  • Parking brake, electric
  • Radiator, wider core
  • Radiator mask, swing out
  • Rear full fenders
  • Rims for 26.5-25 tires
  • ROPS/FOPS Cab Level 2
    - 2 x DC12V electrical outlets
    - Ashtray
    - Auto air conditioner
    - Cigarette lighter, 24V
    - Color LCD/TFT multi-monitor
    - Cup holder
    - Floor mat
    - Operator seat, reclining, air suspension type, heated
    - Radio, AM/FM with AUX input jack
    - Rear defroster, electric
    - Seatbelt, 2-point retractable, 3" width
    - Space for Lunch box
    - Steering wheel, tilt and telescopic
    - Sun visor, front window
    - Windshield washer and wiper, front with intermittent
    - Windshield washer and wiper, rear
  • Service brakes, wet disc type
  • Starting motor, 7.5 kW
  • Transmission KHMT infinitely variable with 4 forward/reverse virtual gear settings
  • Vandalism protection kit, padlocks for battery box (2)
  • 3-spool valve with lever and piping
  • Auxiliary steering (SAE)
  • Cutting edge (bolt-on type)
  • Engine pre-cleaner with extension
  • Limited slip differential (F&R)
  • Various tire options, radial and bias
  • Various bucket options
  • 3-spool valve with lever and piping
  • Auxiliary steering (SAE)
  • Cutting edge (bolt-on type)
  • Engine pre-cleaner with extension
  • Limited slip differential (F&R)
  • Various tire options, radial and bias
  • Various bucket options
Support you can count on

Find what works for you
