If you want a dozer that’s equally at home performing heavy site prep and accurate fine work, this model is an excellent choice. Powered by a fuel efficient, environmentally friendly EPA Tier 4 Final certified engine, it offers your operators a quiet, comfortable cab that provides unrivaled blade visibility. It’s engineered to get jobs done quickly and accurately with its outstanding blade response, fast work equipment speed, an additional “fast-blade mode” that boosts blade speed for high-speed grading, and surprising maneuverability via full power to both tracks during turns or counter rotation steering.
| Model | Komatsu SAA4D95LE-7* |
| Type | 4-cycle, water-cooled, direct injection |
| Aspiration | Variable flow turbocharged, air-to-air aftercooled |
| Number of cylinders | 4 |
| Bore x stroke | 95 x 115 mm |
| Piston displacement | 3.26 L |
| Governor | All-speed, electronic |
| Horsepower: | |
| SAE J1995 - Gross | 79 kW |
| ISO 9249 / SAE J1349 - Net | 78 kW |
| Rated rpm | 2 200 rpm |
| Fan drive type | Hydraulic |
| Lubrication system: | |
| Method | Gear pump, force lubrication |
| Filter | Full-flow |
| *EPA Tier 4 Final emissions certified |
| Model | Komatsu SAA4D95LE-7* |
| Type | 4-cycle, water-cooled, direct injection |
| Aspiration | Variable flow turbocharged, air-to-air aftercooled |
| Number of cylinders | 4 |
| Bore x stroke | 3.75 x 4.52 in |
| Piston displacement | 199 in³ |
| Governor | All-speed, electronic |
| Horsepower: | |
| SAE J1995 - Gross | 107 HP |
| ISO 9249 / SAE J1349 - Net | 105 HP |
| Rated rpm | 2,200 rpm |
| Fan drive type | Hydraulic |
| Lubrication system: | |
| Method | Gear pump, force lubrication |
| Filter | Full-flow |
| *EPA Tier 4 Final emissions certified |
Dual-path, hydrostatic transmission provides infinite speed changes up to 8.5 km/h. The variable capacity travel motors allow the operator to select the optimum speed to match specific jobs. Travel control lock lever and neutral switch.
| Travel speed (quick shift mode)* |
Forward | Reverse |
| 1st | 0–3.4 kph | 0–4.1 kph |
| 2nd | 0–5.6 kph | 0–6.5 kph |
| Travel speed (variable mode) |
0–8.5 kph | 0–8.5 kph |
*Quick shift speeds are adjustable in the monitor.
Dual-path, hydrostatic transmission provides infinite speed changes up to 5.3 mph. The variable capacity travel motors allow the operator to select the optimum speed to match specific jobs. Travel control lock lever and neutral switch.
| Travel speed (quick shift mode)* |
Forward | Reverse |
| 1st | 0–2.1 mph | 0–2.5 mph |
| 2nd | 0–3.5 mph | 0–4.0 mph |
| Travel speed (variable mode) |
0–5.3 mph | 0–5.3 mph |
*Quick shift speeds are adjustable in the monitor.
In-shoe mounted, axial-piston-type travel motors, with integrated two-stage planetary gear reduction. Compact, in-shoe mount reduces risk of damage by debris. Bolt-on sprocket ring with triple labyrinth seal design.
In-shoe mounted, axial-piston-type travel motors, with integrated two-stage planetary gear reduction. Compact, in-shoe mount reduces risk of damage by debris. Bolt-on sprocket ring with triple labyrinth seal design.
Palm Command Control System (PCCS) joystick control for all directional movements. Pushing the joystick forward results in forward machine travel, while pulling it back reverses the machine. Simply tilt the joystick to the left or right to make a turn. Tilting the joystick fully to the left or right activates counter-rotation.
Hydrostatic Transmission (HST) provides smooth, powerful turns. Fully electronic control enables smooth control that can be adjusted in the monitor. The PCCS utilizes shift buttons to increase and decrease speed.
| Minimum turning radius* | 2.4 m |
*As measured by track marks on the ground at pivot turn.
Palm Command Control System (PCCS) joystick control for all directional movements. Pushing the joystick forward results in forward machine travel, while pulling it back reverses the machine. Simply tilt the joystick to the left or right to make a turn. Tilting the joystick fully to the left or right activates counter-rotation.
Hydrostatic Transmission (HST) provides smooth, powerful turns. Fully electronic control enables smooth control that can be adjusted in the monitor. The PCCS utilizes shift buttons to increase and decrease speed.
| Minimum turning radius* | 94 in |
*As measured by track marks on the ground at pivot turn.
Suspension: Rigid type
Track roller frame: Monocoque, large section, durable construction
Rollers & idlers: Lubricated track rollers
Sealed & lubricated track: Track tension easily adjusted w/grease gun
|
D39PX-24 Narrow |
D39PX-24 Wide |
|
| Number of track rollers (each side) | 6 | 6 |
| Type of shoes (standard) | Single grouser | Single grouser |
| Number of shoes (each side) | 39 | 39 |
| Grouser height | 47 mm | 47 mm |
| Shoe width (standard) | 635 mm | 700 mm |
| Ground contact area | 29 782 cm² | 32 970 cm² |
| Ground pressure (with dozer, ROPS cab) |
30.1 kPa / 0.31 kgf/cm² | 27.4 kPa / 0.28 kgf/cm² |
| Track gauge | 1 810 mm | 1 810 mm |
| Length of track on ground | 2 345 mm | 2 345 mm |
Suspension: Rigid type
Track roller frame: Monocoque, large section, durable construction
Rollers & idlers: Lubricated track rollers
Sealed & lubricated track: Track tension easily adjusted w/grease gun
|
D39PX-24 Narrow |
D39PX-24 Wide |
|
| Number of track rollers (each side) | 6 | 6 |
| Type of shoes (standard) | Single grouser | Single grouser |
| Number of shoes (each side) | 39 | 39 |
| Grouser height | 1.9 in | 1.9 in |
| Shoe width (standard) | 25 in | 27.5 in |
| Ground contact area | 4,616 in² | 5,110 in² |
| Ground pressure (with dozer, ROPS cab) |
4.39 psi | 3.98 psi |
| Track gauge | 5 ft. 11 in | 5 ft. 11 in |
| Length of track on ground | 7 ft. 8 in | 7 ft. 8 in |
| Coolant | 34 L |
| Fuel tank | 190 L |
| Engine oil | 11 L |
| Hydraulic tank | 64 L |
| Final drive (each side) | 3.5 L |
| Diesel Exhaust Fluid (DEF) tank | 10 L |
| Coolant | 9.0 US gal |
| Fuel tank | 50.2 US gal |
| Engine oil | 2.9 US gal |
| Hydraulic tank | 17 US gal |
| Final drive (each side) | 0.9 US gal |
| Diesel Exhaust Fluid (DEF) tank | 2.6 US gal |
| Tractor weight: Including ROPS cab, U frame for power angle tilt dozer, rated capacity of lubricant, coolant, full fuel tank, operator, and standard equipment. |
9 200 kg |
| Operating weight: Operating weight: Including power angle tilt dozer, ROPS cab, operator, standard equipment, rated capacity of lubricant, coolant, and full fuel tank. |
10 410 kg |
| Tractor weight: Including ROPS cab, U frame for power angle tilt dozer, rated capacity of lubricant, coolant, full fuel tank, operator, and standard equipment. |
20,282 lbs. |
| Operating weight: Operating weight: Including power angle tilt dozer, ROPS cab, operator, standard equipment, rated capacity of lubricant, coolant, and full fuel tank. |
22,950 lbs. |
