Accessories and upgrades

Multifunctional operator display MOD

Transform the operator experience and streamline serviceability with the multifunctional operator display (MOD), a new dashboard designed exclusively for Komatsu electric drive trucks (EDT). It replaces the traditional single-function gauge panel on 930E-5 and 830E-5 trucks with a contemporary 12-inch, full-color, touchscreen display. More than a visual upgrade, it significantly elevates the operator experience while simplifying the troubleshooting process.

The MOD blends both digital and analog displays for easy reading. With touchscreen controls and an intuitive menu, it is highly user-friendly and can be operated even with gloves on. Its integrated brightness control helps ensure optimal visibility day or night.

For the service team, this new dashboard provides seven times more screen area dedicated to fault alerts. It offers clear, unabbreviated fault descriptions. Expandable languages support broadens global operability. Moreover, the MOD keeps a recent fault history on board, streamlining the troubleshooting process.

Elevate your operator’s experience – Designed with the operator in mind, the MOD combines a modern interface, streamlined navigation and glove-friendly touchscreen controls

Boost service efficiency – Gain quick access to extended fault history with clear text in a large, dedicated area of the screen. No need to figure out abbreviations in a single line of text

Optimize inventory – Stock only a single component to support compatible upgraded and OEM trucks

Future-proof your display – Upgradable software ensures that your display remains at the forefront of technological advancements

Operate with comfort – Bright display for daylight operation is easily dimmed at night or anytime in between

830E wet disc brakes

Help enhance your operator's stopping performance even in adverse conditions by converting your conventional dry disc brakes to wet disc brakes with the Komatsu 830E conversion kit. Wet disc brakes help extend brake life by dissipating heat energy more efficiently and help minimize friction material wear by transmitting torque through oil shear principles.

Komatsu wet disc brakes can help:

• Improve braking performance
• Extend brake life
• Reduce maintenance costs
• Work more effectively in wet conditions
• Optimize operation with a single combo brake pedal with integral retard braking

New components include:

• Remote-mounted 10-gallon accumulator (replaces 2.5-gallon accumulator)
• Spindle hubs (2)
• Speed sensors
• Heat exchanger
• Brake cooling manifold
• Brake relay
• Hoist valve with new tubes and hoses
• Interface module 2 (IM2)

Contact us

Komatsu Premium Seat

• 58E-57-10120 Premium operator seat
• 58E-57-10130 Premium passenger seat
• Upgrade option for the standard operator and passenger seats provided from factory

Features and benefits

• Designed for improved operator comfort
• Seat belt reminder system
• Heated for cold weather climates
• Adjustable side bolsters
• Adjustable air lumbar support

Contact us

Autonomous Haulage System retrofit

Convert your current fleet to autonomous capabilities without the full capital investment of new autonomous machines using the Komatsu AHS Retrofit kits. Potentially increase production and help to reduce wear on components normally affected by an operator.

Advantages of retrofits:

• Added autonomous capabilities to existing machines may avoid new fleet purchases
• Maintenance training on standard truck features remains constant
• Designed to increase component life
• Built to extend tire life
• Engineered to help boost productivity through truck utilization

Requirements:

• Special features request (SFR) required for all AHS conversions
• SFR requirement summary:
• KomVision
• Canopy dimensions for mast selection
• GE cabinet configuration
• Engine HP
• Serial numbers
• ATR from factory
• 3rd party options such as extended bumpers, CAS, etc.

Contact us

Machine Intervention System MIS Kit

Give your haul truck operators increased situational awareness to navigate their surroundings effectively by connecting your third-party PDS to the haul truck via the Komatsu Machine Intervention System (MIS) kit. This system is designed to interact with third-party proximity detection systems (PDS) that enable your haul truck operators with real-time alerts and vehicle status updates so they can make informed decisions to enhance their performance.

The system's machine intervention controller (MIC) connects to the truck's internal Controller Area Network bus (CANbus) and serves as an interface between your third-party PDS and the truck’s information network. By collecting real-time data from the truck and allowing for predefined interventions from the PDS (such as applying the service brake or inhibiting motion), your operators can confidently maneuver around the work site to help boost operational efficiency.

Operators get this real-time feedback through the haul truck’s indicator panel and receive audible warning alarms in the cab so that they can monitor the intervention status and overall system health.

Features and Benefits

Enhance your capabilities

This kit integrates with third-party proximity detection systems (PDS) by sharing real-time performance data. Report up to 16 different data types like truck speed, gross vehicle weight (GVW), inclinometer data and more.

Allow third-party technologies to call for control intervention

A third-party PDS can set specific parameters within the mine, and if the conditions are not met, a signal can be transmitted to the MIC to apply a specific intervention.

Prioritizing clear communication

Easy-to-understand icons and audible warnings help communicate information effectively, enabling operators to be aware of actions the PDS is taking.

Download Sell Sheet

Electric drive system

This electric drive system integrates with Komatsu’s trolley assist infrastructure. The system harnesses the benefits of electric power and optimizes its power distribution to help enhance the performance, longevity and environmental impact of your haul trucks.

• Solid-state power for fast response, precision control and durability
• On-demand cooling for enhanced component longevity and simplified maintenance
• Less rotating mechanical parts to help drive efficiency and availability
• Responds smoothly and quickly to promote uptime and productivity

Contact us

EDT automation AHS retrofit kits

Upgrade your existing conventional haul trucks into autonomous or semi-autonomous vehicles with the Komatsu autonomous haulage system (AHS) retrofit kit. This kit is a flexible, cost-effective way to gain all the benefits of autonomous capabilities without completely replacing your existing vehicles.

The Komatsu AHS system integrates advanced technology to help your mining operation leverage its data to optimize your haulage fleet across your entire value chain and promote enhanced safety, efficiency and productivity.

The Komatsu AHS retrofit kit can help:

• Add autonomous capabilities to your existing machines to avoid investing in costly new machines
• Enable data-driven decision-making to promote operational improvements
• Enhance productivity with predictable, consistent performance and optimized truck utilization
• Control total cost of ownership by driving a fuel-efficient operation
• Promote zero harm by removing operators from potentially hazardous mining environments
• Extend tire life by managing haul routes, truck speeds and movement
• Manage maintenance costs by monitoring equipment performance and spotting issues before they become serious problems

Contact us

Fuel saver II

Fuel Saver II is available for in-situ installation on Komatsu haul trucks. The overall fuel consumption reduction is achieved using advanced software that adjusts the engine rpm in the truck’s different operating stages.

Advantages:

• Lower operating cost
• Reduced carbon emissions
• Fewer fuel stops
• Potential fuel reduction

Fuel Optimization Kit consists of:

• Drive system software upgrade
• Engine control module (ECM) software upgrade
• Interface module software upgrade
• New 24-volt control cabinet wiring harness

Note: In order to take advantage of this upgrade, equipment must meet the following prerequisites: Special feature request (SFR) and mine study; drive system update and software key; ECM software upgrade; interface module software update; 24-volt control cabinet wiring harness (dependent on truck vintage); the latest software for IM and Invertex systems; and Invertex II control system or Minimum Invertex IE control system with: x1 (174, 187, or 197) cards in the PSC and x1 (187, or 197) in the TCI slot, and x2 17FB190 cards in both inverter slots (reference: KMN2014014). Before activation or installation, mine-specific data, such as: operating altitude, ambient operating temperatures and haul profiles must be reviewed and approved by Komatsu’s Global Mining Solutions team.

Contact us

Smartzone Proximity System

As you help your operators work safely around continuous miners through training, the Smartzone Proximity System can supplement your program. This training aid for continuous miner operators and section personnel helps them learn to remain outside of a hazardous “shutdown zone” while operating or working in the vicinity of the continuous miner.

The Smartzone Proximity System:

• Recognizes and monitors personnel movement around equipment
• Is compatible with Joy room and pillar products
• Features advanced technology with:
  • Plug-and-play capabilities
  • Equipment-specific zone configurations
  • Faceboss Control System integration
  • Machine-integrated drivers
• Has diagnostic capabilities available
• Features MSHA-approved wearable devices

Contact us

Download brochure

Smart rims

The seven-piece Smart Rim was designed with additional Bead Seat bands and Smart Lock Rings, unlike the traditional five-piece rim system. This allows maintenance personnel to install and remove the rear tires on the rear axle without having to remove the rim.

Advantages:

• Easier tire removal
• Reduced tire maintenance time by as much as 50% vs. traditional five-piece rim systems

Kit Contents:

• Two complete rear outer Smart Rim assemblies
• Special Lock Ring expander tool
• Four Smart Lock Rings for the rear inner rims and the front rim

Contact us

Proximity detection

Komatsu has developed a personal proximity detection system for use on the longwall face to help control automated shield movements when personnel are nearby. This system utilizes fully integrated low-power wireless transceivers in each RS20s Faceboss mimic to determine the location of each person wearing a battery-powered tag or personal wearable device (PWD). The PWD currently uses relative RF signal strength and an accelerometer to locate the operator's position.

• Existing RS20s systems can be upgraded to operate personal proximity detection by simply upgrading the mimic to the latest Faceboss version.
• Komatsu’s proprietary web-based user interface Longwall Information System (LIS) is utilized to set up the system and display live tracking information.
• Safety standards:
  • IEC61508 SIL 1 - Certified safety system
  • Sira 13 ATEX - Europe
  • IECEx SIR - International
  • MSHA Approval - United States

Contact us

Quad Chopper

The Quad Chopper upgrade kit is used to upgrade current drive systems using RP Contactors in the control system, through the addition of maintenance- and inspection-free solid-state inverters. Replacing the RP Contactors with the solid-state inverters helps to improve reliability and overall performance of your drive system.

Advantages:

• Helps reduce maintenance wear parts
• Lessens unscheduled downtime events
• Promotes reliability
• Mitigates damage from RP Contractor flashover

Requirements:

• Invertex II control system or
• Minimum Invertex IE control system with:
• x1 (174, 187 or 197) cards in the PSC and x1 (187 or 197) in the TCI slot and
• x2 17FB190 cards in both inverter slots
• As well as the latest software for IM and Invertex systems

Contact us

Wireless bridge kits

Get the real time communication ability of a wired system with the ease and convenience of wireless communication.

Other features and advantages:

• Can be installed without technician assistance, typically in about four hours
• Programable download intervals
• Downloads for multiple trucks simultaneously

Requirements: Access point (usually at a fueling area or in a pickup truck); Haul truck equipped with kit and MikroTik CPE-configured bridge; MikroTik radio must be sourced locally; Laptop loaded with Komtrax Plus PC Tools.
