Forestry
895-2
Forwarders
- Gross load capacity (kg) 20 000
- Gross load capacity (lbs) 44,092
- Horsepower (HP) 287 HP @ 1,850 rpm
- Horsepower (kW) 214 kW @ 1 850 rpm
- Tractive force (kN) 262
- Tractive force (lbf) 58,900
Power to deliver
For your big log-hauling challenges, the 895 is designed to be your most trusted partner. Each component was developed to confidently handle a load up to 20 metric tons. Hydraulic retarder overspeed protection ensures the driveline won't run too fast.
- Choose the right machine for the job with four load-capacity options
- Drive high productivity with powerful cranes and rugged FlexBunks
- Tackle the roughest terrain with powerful hydrostatic transmission and high ground clearance
Resources
Features and benefits
Efficient loading
Match the machine to the job with a variety of load capacities — 12, 14, 16 or 20 metric tons — and several frame-length options. Designed for smooth and precise operation. Rugged cranes have a long reach and excellent lifting and slewing torque.
Smooth, fast transport
Maneuver with confidence in the most rugged forests, even when fully loaded. Chassis and suspensions are designed for performance under demanding conditions. Komatsu Comfort Bogie axles with a high portal offset and V-shaped frames provide some of the highest ground clearance in the industry.
Operator comfort
Operator comfort is key to your productivity. Spacious and open, our cab provides fantastic visibility, ergonomic controls and a seat that delivers all-day comfort. Optional Comfort Ride suspension provides added comfort and capabilities.
Powerful yet efficient
Maximize performance with high power and torque while driving efficiency with a fuel-efficient engine. A sophisticated control system automatically adapts to changes in engine load.
Technology-driven traction
Get exceptional tractive force thanks to an intelligent hydrostatic transmission system that considers machine load, terrain conditions, power and torque output. Hydraulic retarder overspeed protection on the 875-1 and 895-2 models ensures the driveline won't run too fast.
Customize your controls
Give operators the benefit of machine controls they can fine-tune for sensitivity and speed or smoothness and accuracy – whatever the job demands. Our state-of-the-art MaxiXplorer/MaxiXT system monitors and controls everything from engine and crane to the transmission and service ladders.
Easy to maintain
Less time servicing means more time forwarding. Maintenance is quickly and easily completed with a service-friendly design featuring an electronically powered tilting hood. All filters are located together for easy access under the hood.
Overcome climbing obstacles
When you need to do ground or stump leveling on tough terrain, an optional heavy-duty stacking blade is available. Mounted with a high angle of departure for climbing obstacles, there’s no interference between blade, battery boxes or hood guard.
Options for added benefit
Multiple options are available to enhance your productivity and comfort, including bunk wideners, rear- and front-view video cameras, computer touchscreen and electric fuel fill pump.
Cold weather starting
Don’t lose valuable time when the temperatures drop. A standard diesel heater system heats the engine coolant, hydraulic oil and the batteries to facilitate cold-weather starting on the 845-1, 855-3, 875-1 and 895-2.
Specifications
- Full specs
- Driving speed (kph): 0 - 23
- Driving speed (mph): 0 - 14.3
- Tractive force (lbf): 58,900
- Tractive force (kN): 262
- Type, Europe and North America: AGCO Power, 6-cylinder diesel engine with turbo and intercooler. Tier 4 F.
- Power, max.: (kW): 214 kW DIN @ 1 850 rpm
- Torque (Nm): 1 280 Nm @ 1 500 rpm
- Fuel tank (L): 220
- Fuel tank (US gal): 58.1
- Stroke volume (L): 7,4
- Stroke volume (US gal): 1.95
- Loader type: Komatsu 165F
- Flow (L/min): 360 @ 2 000 rpm
- Flow (gpm): 95 @ 2,000 rpm
- System pressure (psi): 3,553
- System pressure (bar): 245
- Reach (ft): 24 ft. 7 in - 27 ft. 11 in
- Reach (m): 7.5 - 8.5
- LIfting torque, gross (lbs-ft): 121,698
- LIfting torque, gross (kNm): 165
- Slewing torque, gross (kNm): 43.4
- Slewing torque, gross (lbs-ft): 32,010
- Rotator: G121/G141/G171 ProTec 2
- Grapple: Komatsu G36
- Approximate weight (kg): 6WD: 20 400 kg; 8WD: 23 600 kg
- Approximate weight (lbs): 6WD: 44,974 lbs.; 8WD: 52,029 lbs.
- Specification details: The specifications describe possible equipment, not which equipment is standard or optional. Standard and optional equipment varies between countries. Your sales representative has an up-to-date list of what is included. Weights are based on the equipment specified in the basic specification. Specifications and designs are subject to alteration without prior notice.
- Gross load (lbs): 44,092
- Gross load (kg): 20 000
- Bunk area (m^2): 5.2 - 7.2 m²
- Bunk area (sq. ft): 56 - 77.5
- Width (mm): With 780/50x28,5 tires: 3 160 mm
- Width (ft): With 780/50x28,5 tires: 10 ft. 4 in
- Length, total (with shortest rear frame)(mm): 10 790
- Length, total (with shortest rear frame)(ft): 35 ft. 5 in
- Length, front axle to articulated joint (ft): 6 ft. 7 in
- Length, front axle to articulated joint (mm): 2 000
- Length, articulated joint to rear axle (with shortest rear frame): 12 ft. 10 in
- Length, articulated joint to rear axle (with shortest rear frame)(mm): 3 900
- Transport height: 13 ft. 3 in (hoses included and with tire compression)
- Transport height with hoses and tyre compression: 4 050 mm (hoses included and with tire compression)
- Ground clearance, at steering clearance: 8WD: 790 mm
- Ground clearance, at steering coupling: 8WD: 2 ft. 7 in
- Note on dimensions: Stated dimensions are nominal and may vary slightly depending on production tolerances and choice of equipment.
- Voltage: 24 V
- Battery capacity: 2 x 180 Ah
