Excavators

PC490LCi-11

Large excavators

  • Engine power (HP) 359
  • Engine power (kW) 268
  • Bucket capacity (m^3) 2.7
  • Bucket capacity (yd^3) 3.53
  • Operating weight (kg) 48920
  • Operating weight (lbs) 107889

Purchase options

Request a quote Rent me

Excellent for mass excavating, trenching, or fine grading, our largest intelligent machine excavator can increase your productivity and efficiency without the worry of over-excavation from first to last pass, straight to grade. The PC490LCi-11 is designed for heavy construction, quarrying and demolition applications, delivering high productivity and lower owning and operating costs. Key components are designed and manufactured by Komatsu to work together in an integrated package. And it comes standard with our Komtrax remote monitoring and location system, backed by our Australia-wide service and support network.

    Resources

    Features and benefits

    Adjusts to the operator's experience level

    Adjusts to the operator's experience level

    A fully integrated grade assist automatically traces the target surface to minimise over digging. A built-in facing angle compass ensures the machine is aligned with the target surface.

    Auto stop control

    Auto stop control

    To help eliminate potential damage during boom or bucket operation, the machine automatically stops when the bucket edge reaches the design surface.

    Comfortable working space

    Comfortable working space

    The wide spacious cab includes a heated air suspension seat with reclining backrest. The seat height and position are easily adjusted using a pull-up lever. The armrest position is easily adjusted together with the console. Reclining the seat further enables it to be fully laid back with the headrest attached.


    Specifications

    Metric Imperial (US)
    Expand all

    • Drive method: Fully hydrostatic
    • Swing reduction: Planetary gear
    • Swing circle lubrication: Grease-bathed
    • Service brake: Hydraulic lock
    • Holding brake/Swing lock: Mechanical disc brake
    • Swing speed (rpm): 9.1
    • Driven by: Hydraulic motor

    • HydrauMind Type: HydrauMind System

    • Hydraulic cylinders

      • Arm (Number of cylinders – bore x stroke x rod diameter)(in): 7.28 x 71.65 x 4.72
      • Arm (Number of cylinders – bore x stroke x rod diameter)(mm): 1-185 x 1820 x 120

    • Main pump

      • Pumps for: Boom, arm, bucket, swing, and travel circuits
      • Maximum flow (US gpm): 206.05
      • Maximum flow (L/min): 780

    • Relief valve setting

      • Travel: 2 x axial piston motor with parking brake
      • Swing: 1 x axial piston motor with swing holding brake
      • Implement circuits (psi): 5404.85
      • Travel circuit (psi): 5405
      • Implement circuits (MPa): 37.27
      • Swing circuit (psi): 4054
      • Implement circuits (kgf/cm^2): 380
      • Swing circuit (kgf/cm^2): 285
      • Swing circuit (MPa): 27.94
      • Travel circuit (kgf/cm^2): 380
      • Travel circuit (MPa): 37.3

    • Coolant (US gal): 12.42
    • Engine (US gal): 10.04
    • Swing drive (L): 20
    • Swing drive (US gal): 5.28
    • Hydraulic tank (L): 248
    • Hydraulic tank (US gal): 65.52
    • DEF tank (US gal): 10.3
    • Engine (L): 38
    • DEF tank (L): 39
    • Fuel tank (L): 65
    • Coolant (L): 47

    • Engine Model: Komatsu SAA6D125E-7
    • Aspiration: Turbocharged, aftercooled
    • Piston displacement (L): 11.04
    • Piston displacement (in^3): 673.69
    • Fan drive method for radiator cooling: Hydraulic

    • Horsepower

      • SAEJ1995 - Gross (kW): 270
      • SAEJ1995 - Gross (HP): 362
      • ISO 9249 / SAE J1349 - Net (kW): 268
      • ISO 9249 / SAE J1349 - Net (HP): 359

    • Maximum drawbar pull (kgf): 33510
    • Parking brake: Mechanical disc brake
    • Gradeability: 70 %

    • Center frame: X-frame leg
    • Track frame: Box-section
    • Track adjuster: Hydraulic
    • Number of shoes (each side): 49
    • Number of carrier rollers (each side): 2
    • Number of track rollers (each side): 8

    • Pilot circuit (kgf/cm^3): 33

    • Bucket crowd force - ISO (kgf): 28000
    • Swing radius (in): 143.5
    • Boom size (m) and type: 7.0 heavy duty
    • Maximum reach at ground level (mm): 11810
    • Digging depth - maximum (mm): 7755
    • Maximum reach at ground level (in): 465
    • Arm size (m) and type: 3.4 heavy duty
    • Arm crowd force - ISO (kgf): 21800
    • Swing radius (mm): 3645

    • Overall track width (in): 131.5
    • Overall track width (mm): 3340
