Room and pillar
1032C series
Shuttle cars
- Rated load capacity (mt) 11 - 30
- Rated load capacity (st) 12 - 33
- Minimum seam height (cm) 135 - 264
- Minimum seam height (in) 53 - 104
- Conveyor (HP) 23 - 34 HP
- Conveyor (kW) 17 - 25 kW
Choose a model that best meets your needs
Seven models give you operational flexibility in a wide range of applications. Give your operators the ability to move efficiently, even in the tightest spaces with the superior maneuverability of four-wheel drive traction and steering.
- Built for harsh conditions
- OptiDrive designed to enhance performance
- Range of models to fit your requirements
- Engineered for maximum production
Resources
Features and benefits
Heavy-duty design
Designed for reliability with heavy-duty conveyor reducers and abrasion-resistant decking and chassis and rolling gears designed for optimal balance of volumetric load, vehicle dimensions, load-carrying ability and fatigue life.
A smooth ride
For uneven or broken roadways, Joy shuttle cars’ four-wheel independent suspension mitigates energy transferred to the chassis, designed for longer machine life and to help reduce operator fatigue.
Simplified maintenance
With a swing-out controller and swing-out pump compartment, easy access to hose and cables helps reduce maintenance time. Lighting options and zoned-out difficult-to-access grease points further facilitate maintenance.
Customizable conveyor system
Variable frequency drive (VFD) conveyor reduces the shock loading of all key conveyor drive components to help ensure the reliability and availability of the conveyor system. Operators can adjust discharge rates to match the mine belt infrastructure.
Permanent four-wheel drive
All-time four-wheel drive system helps performance on soft bottoms and grades. Powered by two 85kW VFD AC traction motors (50 kW in lower seam models).
Outstanding maneuverability
Four-wheel steering provides deft operation in narrow roadways. Non-suspension shuttle cars have crab steering, enabling an operator to turn all four wheels in the same direction for additional maneuverability.
Onboard cameras (optional)
Exceptional visibility using infrared or black-and-white cameras. One forward and one rearward-looking monitor are mounted in the operator’s compartment.
Improve air quality
To help supply clean air for your operators, positive pressure is maintained by a hydraulically powered motor operating both blower and air conditioner in the operator compartment. Filter improves air quality. Available as an OE option on new cars, or a kit for existing cars.
Remote control to extend your operations
An optional remote-control system can increase productivity of your room and pillar operations. An unmanned shuttle car can follow a continuous miner under an unsupported roof section, allowing for deeper cuts.
Specifications
- Full specs
Metric
Imperial (US)
Expand all
- Weight (kg): 21 000 - 39 000 (with 56 in conveyor)
- Weight (lbs): 46,000 - 86,000 (with 56 in conveyor)
- Ground pressure (psi): 109 - 157 (with 56 in conveyor)
- Ground pressure (kg/cm^2): 7.7 - 11.1 (with 56 in conveyor)
- Length (m): 8.7 - 9.7
- Length (ft): 28 ft. 7 in - 31 ft. 11 in
- Width (in): 132 - 152 (with 56 in conveyor)
- Width (m): 3.35 - 3.85 (with 56 in conveyor)
Support you can count on
Technology that works as hard as you do
- Joy Connect
- VFD Conveyor Drive
- Cameras
Select continent
VFD Conveyor Drive
Variable frequency drive (VFD) conveyor reduces the shock loading of all key conveyor drive components to help ensure the reliability and availability of the conveyor system. Operators can adjust discharge rates to match the mine belt infrastructure.
Cameras
Operators can perform more quickly and safely when they can easily see what’s in front of and behind the hauler. Optional forward and rearward FLIR cameras, mated to monitors in operator compartment, help operators be sure of their surroundings.
