Dozers

D85PXi-18

Large dozers

  • Horsepower (HP) 264 HP @ 1,900 rpm
  • Horsepower (kW) 197 kW @ 1 900 rpm
  • Operating weight (kg) 29 700
  • Operating weight (lbs) 65,460
  • Blade capacity (m^3) 5.9
  • Blade capacity (yd^3) 7.7

Purchase options

Request a quote Find a dealer

A workhorse for your fleet

Need a powerful, economical dozer with outstanding floatation? You'll appreciate the D85PXi-18's 11-liter engine, 14' 4” straight tilt blade, fuel-efficient automatic transmission and expansive footprint for soft ground conditions. Optional extended wear life undercarriage with 36” wide PLUS (Parallel Link Undercarriage System) rotating bushing track shoes is available.

  • Get new operators up to speed quickly
  • Go from mass ex to finished grading faster than ever
  • Fully integrate 3D design data into your machines
  • Empower operators to work efficiently, pass after pass

Features and benefits

Close the operator skill gap

Close the operator skill gap

Machine logic allows the dozer to continuously learn the terrain and make calculated decisions for the next pass. Intelligent Machine Control helps lessen the skill gap between new and experienced operators.

Advanced machine control

Advanced machine control

In select situations — auto stripping, rough dozing, spreading, advanced finish grading — operators can opt for nearly 100% machine control auto usage. They can even apply automatic control without having a 3D model.

A machine that learns from the operator

A machine that learns from the operator

Automatic functions give the dozer the ability to learn from operator's blade input, resulting in more adaptability, easier operation and less reliance on operator input.

Outstanding blade response for finish grading

Outstanding blade response for finish grading

To deliver unparalleled grading performance, IMC enables the dozer to look ahead at grade transitions and alter the blade angle accordingly.


Specifications

Metric Imperial (US)
Expand all

  • Suspension: Oscillating equalizer bar and pivot shaft
  • Track roller frame: Monocoque, large section, durable construction
  • Rollers and idlers: Lubricated
  • Type of shoes (standard): Single grouser
  • Number of track rollers (each side): 8
  • Number of shoes (each side): 45
  • Lubricated tracks: Lubricated tracks. Unique seals prevent entry of foreign abrasive material into pin to bushing clearances to provide extended service life. Track tension is easily adjusted with grease gun.
  • Grouser height (in): 2.8
  • Grouser height (mm): 72
  • Shoe width (standard)(in): 36
  • Shoe width (standard)(mm): 910
  • Ground contact area (cm^2): 70 780
  • Ground contact area (ft2): 76.2
  • Ground pressure (with standard shoe)(ISO 16754)(psi): 5.2
  • Ground pressure (with standard shoe)(ISO 16754)(kpa): 36
  • Ground pressure (with standard shoe)(ISO 16754)(kg/cm^2): 0.36
  • Track gauge (ft): 7 ft. 5 in
  • Track gauge (mm): 2 250
  • Length of track on ground (mm): 3 480
  • Length of track on ground (ft): 11 ft. 5 in

  • Hydraulic system features: Closed-Center Load Sensing System (CLSS) designed for precise and responsive control, and for efficient simultaneous operation.
  • Hydraulic control unit (U.S. gal/min): All spool valves externally mounted beside the hydraulic tank. Piston type hydraulic pump with capacity (discharge flow) of 87.4 US gpm at rated engine rpm.
  • Hydraulic control unit (ltr/min): All spool valves externally mounted beside the hydraulic tank. Piston type hydraulic pump with capacity (discharge flow) of 331 L/min at rated engine rpm.
  • Relief valve setting (psi): 3,270
  • Relief valve setting (MPa): 22.6
  • Control valve: Spool control valves for SIGMADOZER®, semi-u tilt or straight tilt dozer
    • Positions

      • Blade lift: Raise, hold, lower, and float
      • Blade tilt: Right, hold, and left
      • Rear attachment: Raise, hold and lower

  • Engine Model: Komatsu SAA6D125E-7*
  • Dozers type: 4-cycle, water-cooled, direct injection
  • Aspiration: Komatsu variable geometry turbocharged, air-to-air aftercooled
  • Number of cylinders: 6
  • Bore x stroke (in): 4.49 x 5.69
  • Bore x stroke (mm): 125 x 150
  • Piston displacement (L): 11.04
  • Piston displacement (in^3): 674
  • Governor: All-speed and mid-range, electronic
  • Footnote: *EPA Tier 4 Final emissions certified
  • Horsepower

    • SAEJ1995 - Gross (HP): 267
    • SAEJ1995 - Gross (kW): 199
    • ISO 9249 / SAE J1349 - Net (HP): 264
    • ISO 9249 / SAE J1349 - Gross (kW): 197
    • Rated RPM: 1,900
    • Fan drive type: Hydraulic
  • Lubrication system

    • Filter: Full-flow
    • Method: Gear pump, force lubrication

  • Transmission features: Komatsu TORQFLOW transmission consists of a water-cooled, 3-element, 1-stage, 1-phase and a planetary gear, multipledisc clutch transmission which is electronically controlled, hydraulically actuated and force-lubricated for optimum heat dissipation. Shift lock lever and neutral safety switch.
  • Reverse

    • 1st torqflow reverse (kph): 4.4
    • 1st torqflow reverse (mph): 2.7
    • 2nd torqflow reverse (mph): 5
    • 2nd torqflow reverse (kph): 8
    • 3rd torqflow reverse (kph): 13
    • 3rd torqflow reverse (mph): 8.1
    • 3rdL torqflow reverse (mph): 5.7
    • 3rdL torqflow reverse (kph): 9.2
  • Forward

    • 1st torqflow forward (mph): 2.1
    • 1st torqflow forward (kph): 3.3
    • 2nd torqflow forward (mph): 3.8
    • 2nd torqflow forward (kph): 6.1
    • 3rd torqflow forward (mph): 6.3
    • 3rd torqflow forward (kph): 10.1
    • 3rdL torqflow forward (kph): 7.8
    • 3rdL torqflow forward (mph): 4.8

  • Fuel tank (L): 470
  • Fuel tank (US gal): 124.1
  • Diesel Exhaust Fluid (DEF) tank (US gal): 6.2
  • Diesel Exhaust Fluid (DEF) tank (L): 23.5
  • Coolant (US gal): 17.2
  • Coolant (L): 65
  • Engine oil (US gal): 10
  • Engine oil (L): 38
  • Damper case (L): 1.6
  • Damper case (US gal): 0.42
  • Torque converter, transmission, bevel gear, and steering system (L): 60
  • Torque converter, transmission, bevel gear, and steering system (US gal): 15.8
  • Final drive (US gal): 9.6
  • Final drive (L): 36

  • Steering system features: Palm Command Control System (PCCS) lever controls for all directional movements. Pushing the PCCS lever forward results in forward machine travel, while pulling it rearward reverses the machine. Simply tilt the PCCS lever to left to make a left turn. Tilt it to the right for a right turn. Hydrostatic Steering System (HSS) is powered by steering planetary units and an independent hydraulic pump and motor. Counterrotation turns are also available. Wet, multiple-disc, pedal-controlled service brakes are spring-actuated and hydraulically released. Gear shift lock lever also applies parking brake.
  • Minimum turning radius (in): 87
  • Minimum turning radius (m): 2.2

  • Operator weight (approximate): Including SIGMADOZER  and fixed multi-shank ripper (EXi) or straight tilt dozer and long drawbar (PXi) ROPS cab, operator, standard equipment, rated capacity of lubricant, hydraulic control unit, coolant, and full fuel tank.
  • Tractor weight

    • Tractor weight (lbs): 57,849
    • Tractor weight (kg): 26 210
    • Tractor weight inclusions: Including ROPS cab, rated capacity of lubricant, hydraulic control unit, coolant, full fuel tank, operator, and standard equipment.
  • Operating weight

    • Operating weight (kg): 29 700
    • Operating weight (lbs): 65,460

  • Final drive features: Double-reduction final drive of spur and planetary gear sets to increase tractive effort and reduce gear tooth stresses for long final drive life. Segmented sprocket teeth are bolt-on for easy replacement. Triple labyrinth protects seals and improves durability.
Metric Imperial (US)
  • Air cleaner, double element with dust indicator
  • Alternator, 90 ampere/24V
  • Auto idle shutdown function
  • Backup alarm
  • Batteries, 200 Ah/2 x 12V
  • Battery disconnect switch
  • Blade lift cylinders
  • Color monitor, LCD
  • Decelerator pedal
  • Engine hood
  • Engine intake centrifugal precleaner
  • Engine, gull-wing side covers
  • Exhaust pipe with raincap
  • Fenders
  • Front pull hook
  • High mount foot rests
  • Horn, warning
  • Hydraulic driven radiator cooling fan with reverse clean mode
  • Hydraulics for front attachment
    --Single tilt, power pitch (EX SIGMADOZER only)
    --Single tilt, manual pitch (non-SIGMADOZER)
  • KOMTRAX® Level 5
  • Komatsu Diesel Particulate Filter (KDPF)
  • Komatsu Variable Geometry Turbocharger (KVGT)
  • Locks, filler caps and covers
  • Oil pressure check ports for power train
  • Operator ID function
  • PM service connector
  • Radiator mask, heavy-duty, hinged, perorated
  • Radiator reserve tank
  • Rear cover
  • ROPS Cab**
    • 75 dB operator ear noise level
    • Air conditioner
    • Cab accessories
      --12V power supply (2 ports)
      --Cup holder
      --Rearview mirror
      --Rear view monitoring (1 camera)
      --AM/FM Radio w/remote AUX plug (3.5 mm)
    • Work lights
      --2 front, hood mounted
      --2 front, Cab mounted
      --1 rear, left fender mounted
      --2 rear, Cab mounted
      --1 ripper point (EX/EXi only)
  • Seat, air suspension, fabric, heated low back, rotates 12.5° to right, headrest
  • Seat belt, 3", retractable
  • Seat belt indicator
  • Sealed electrical connectors
  • Starting motor, 11.0 kW/24V
  • Steering system: Hydrostatic Steering System (HSS)
  • Torque converter
  • Track roller guards, center and end sections
  • Track shoe assembly
    Heavy Duty rotary bushing (PLUS) track
    - 36” PLUS Extreme Service shoe (PXi)
  • Transmission with auto/manual shift modes
  • Underguards, heavy duty
  • Hinged belly pan
  • Transmission
  • Water separator
  • Wide core cooling package

* Dozer assembly and rear mounted equipment are not included in base machine standard equipment
** Cab meets OSHA/MSHA ROPS and FOPS Level 2 standards (ROPS standards ISO 3471, SAE J/ISO 3471; FOPS standards ISO 3449)

  • Air cleaner, double element with dust indicator
  • Alternator, 90 ampere/24V
  • Auto idle shutdown function
  • Backup alarm
  • Batteries, 200 Ah/2 x 12V
  • Battery disconnect switch
  • Blade lift cylinders
  • Color monitor, LCD
  • Decelerator pedal
  • Engine hood
  • Engine intake centrifugal precleaner
  • Engine, gull-wing side covers
  • Exhaust pipe with raincap
  • Fenders
  • Front pull hook
  • High mount foot rests
  • Horn, warning
  • Hydraulic driven radiator cooling fan with reverse clean mode
  • Hydraulics for front attachment
    --Single tilt, power pitch (EX SIGMADOZER only)
    --Single tilt, manual pitch (non-SIGMADOZER)
  • KOMTRAX® Level 5
  • Komatsu Diesel Particulate Filter (KDPF)
  • Komatsu Variable Geometry Turbocharger (KVGT)
  • Locks, filler caps and covers
  • Oil pressure check ports for power train
  • Operator ID function
  • PM service connector
  • Radiator mask, heavy-duty, hinged, perorated
  • Radiator reserve tank
  • Rear cover
  • ROPS Cab**
    • 75 dB operator ear noise level
    • Air conditioner
    • Cab accessories
      --12V power supply (2 ports)
      --Cup holder
      --Rearview mirror
      --Rear view monitoring (1 camera)
      --AM/FM Radio w/remote AUX plug (3.5 mm)
    • Work lights
      --2 front, hood mounted
      --2 front, Cab mounted
      --1 rear, left fender mounted
      --2 rear, Cab mounted
      --1 ripper point (EX/EXi only)
  • Seat, air suspension, fabric, heated low back, rotates 12.5° to right, headrest
  • Seat belt, 76mm, retractable
  • Seat belt indicator
  • Sealed electrical connectors
  • Starting motor, 11.0 kW/24V
  • Steering system: Hydrostatic Steering System (HSS)
  • Torque converter
  • Track roller guards, center and end sections
  • Track shoe assembly
    Heavy Duty rotary bushing (PLUS) track
    - 910 mm PLUS Extreme Service shoe (PXi)
  • Transmission with auto/manual shift modes
  • Underguards, heavy duty
  • Hinged belly pan
  • Transmission
  • Water separator
  • Wide core cooling package

* Dozer assembly and rear mounted equipment are not included in base machine standard equipment
** Cab meets OSHA/MSHA ROPS and FOPS Level 2 standards (ROPS standards ISO 3471, SAE J/ISO 3471; FOPS standards ISO 3449)

Metric Imperial (US)
  • Drawbar, rigid type
  • Semi-U (EXi)
  • SIGMADOZER® (EXi)
  • Straight tilt (PXi)

Multi-shank ripper (for D85EX)

  • Weight,5,520 lb
  • Beam length,7'5"
  • Maximum lift above ground,1'10"
  • Maximum digging depth,2'2"
  • Drawbar, rigid type
  • Semi-U (EXi)
  • SIGMADOZER® (EXi)
  • Straight tilt (PXi)

Multi-shank ripper (for D85EX)

  • Weight,2500 kg
  • Beam length,2246 mm
  • Maximum lift above ground,565 mm
  • Maximum digging depth,655 mm
