Electric rope shovels

2800XPC

  • 6,285 - 8,381
  • 5 702 - 7 603

Purchase options

Request a quote Find a dealer

Designed for productivity in tough environments.

Engineered for outstanding digging power and faster cycle times, the 2800XPC electric mining shovel is intended to be the productive, reliable, low cost per tonne workhorse of your fleet. Featuring an AC electrical system designed to move materials quickly, the 2800XPC is built to give you years of dependable service even in tough environments.

  • Low cost per tonne loading
  • Designed to deliver high cutting forces

Resources


Specifications

Metric Imperial (US)
Expand all

  • Nominal dipper capacity* (yd^3): 35 - 44
  • Nominal dipper capacity* (m^3): 26.8 - 33.6
  • Rated suspended load (st): 135
  • Rated suspended load (mt): 122.5
  • Nominal payload dipper capacity note: *Payload and dipper capacity are dependent on many factors. Contact Komatsu Mining for an analysis of your specific application.

  • Height of cut (ft): 54 ft. 6 in
  • Height of cut (m): 16.6
  • Radius of cut (ft): 79 ft. 3 in
  • Radius of cut (m): 24.2
  • Dumping height* door open (ft): 30
  • Dumping height* door open (m): 9.1
  • Floor level radius (m): 16.4
  • Floor level radius (ft): 53 ft. 9 in
  • Tail swing radius (m): 9.9
  • Tail swing radius (ft): 32 ft. 6 in
  • Operator eye level (m): 9.6
  • Operator eye level (ft): 31 ft. 4 in
  • Dumping height (footnote): *Height shown with bail-type dipper. Heights will be greater than bail-less or compact-bail dippers. Actual dumping height can be greater than door clearance height.

  • Crowd: Powerband V-belt drive between motor and gear case absorbs shock loads. First and second reduction gearing in enclosed gear case for reliable splash lubrication, ease of maintenance, and extended component life. Twin-leg dipper handle with torsion box and rack and pinion drive has inherent stability in the bank for optimal digging. Spring-set air release disc brake.

  • Swing: Two modular P&H planetary gear cases of proven design and a single piece forged swing gear transmit torque for fast cycle times. Spring-set air release disc brakes – one per motor. Splash lube filtration system.

  • Supply voltage: 4,160 or 7,200 V 3 Phase, 60 Hz or 5,000, 6,000 or 6,600 3 Phase, 50 Hz
  • Supply transformer: Minimum 2,750 kVA (5,000, 6,000 or 6,600 3 phase, 50 Hz supply voltage)
  • Minimum short circuit VA available at shovel: 22 MVA (5,000, 6,000 or 6,600 3 phase, 50 Hz supply voltage)
  • Supply voltage note: *Voltage per customer requirements

  • Propel: Propel on demand provides rapid transfer to propel mode. Rapid transfers allow frequent positioning of the shovel to the bank resulting in faster cycle times and more efficient digging. Two rugged P&H planetary gear cases of proven design independently transmit torque to the drive sprockets, producing the tractive effort required for fast, efficient propel and positioning operations. Delta drive low tension sprocket drive system with heavy duty cast crawler shoes. Spring-set air release disc brakes – one per motor.

  • Hoist for gearing: All gearing housed in single enclosed gear case with filtered and cooled oil fed to all bearings in addition to splash lubrication for reliable operation and ease of maintenance. Large 56 in diameter hoist drum for extended rope bending life. Ferrule becket system and dual electric tuggers are standard for efficient rope change. Spring-set air release disc brakes – one per motor.

Technology

Select continent

Argus

The Argus Payload Monitoring System weighs each bucket in real-time, which helps eliminate the need to stop and calculate payload before loading the truck. Immediate feedback promotes loading accuracy, while peer benchmarking works to reinforce best practices to improve operator performance.

technology-image

ProVision

The ProVision Machine Guidance System promotes increased operator efficiency and productivity through the use of high-precision global navigation satellite system (HP-GNSS) positioning. Capable of providing up to 1 cm accuracy, the ProVision System helps guide shovel operators to dig the right material, keep the designed bench grade, respect dig limits, and work within the machine’s prime operating specifications. The system also provides guidance to truck operators to help promote precise spotting at a loading unit.

technology-image

MineCare

The MineCare Maintenance Management System combines the benefits of real-time remote equipment health monitoring with cloud computing technology and advanced analytics capabilities. The MineCare System promotes the advanced detection of issues before they occur, thus helping to reduce unplanned maintenance events, promoting increased uptime and utilization and reduced maintenance costs and equipment degradation.

technology-image

DISPATCH

The DISPATCH Fleet Management System (FMS) helps mines achieve enhanced load and haul cycle efficiency and productivity through its proprietary optimization algorithm. The DISPATCH FMS provides mines with increased potential for end-to-end monitoring of production and auxiliary equipment, improved compliance with planning objectives, shorter hang/queue times and more.

technology-image

Payload 2

Help your shovel operators hit the truck's target load every time.

technology-image
