Feeder breaker

SFB-29

  • Pick force 1 112 kN 250,000 lbf.
  • Weight 20 - 30 tonnes 22 - 33 tons
  • Throughput Up to 1 500 MTPH Up to 1,655 TPH

Single-source crushing and conveying

For streamlined operation, feeder breakers combine the receiving, sizing and conveying of mineral material into a single unit. For additional efficiency, each model features a specially designed surge hopper, helping trucks and other haulage equipment to discharge material at their maximum rate.

Features and benefits

Komatsu SFB-32 surface feeder breaker loaded by two wheel loaders

Low profile allows flexibility

You have more loading options with a low horizontal profile feeder breaker ― most haulage equipment can discharge directly into the feeder hopper. If you use trucks, the ramp and foundation can be lower and more economical.
Komatsu Crushing Joy-underground-feeder-breaker SFB 29 in mining site

Conveying and crushing in one unit

Simplify your operation with a feeder breaker that combines receiving, feeding and sizing into a single unit.
Komatsu Crushing Joy-underground-feeder-breaker SFB 41 in mining site

Managed output

Get the correct material output size for your operation from breaker picks and pick pattern designed for your operation and conveyor flights.
Komatsu Crushing Joy-underground-feeder-breaker SFB-32 in mining site

Long-life, low-maintenance conveyor chain

To keep the feeder breaker running, the conveyor uses a high strength engineered chain with hardened link pins.
Komatsu Crushing Joy-underground-feeder-breaker GPL12239 in white background

Choose Electro-mechanical or hydraulic conveyor drive

Depending on the needs of your site, choose from a electro-mechanical or hydraulic drive.
Komatsu Crushing Joy-underground-feeder-breaker SFB-32 in mining site

Mobility options to match your operation

All feeder breakers can be fitted with skids, wheels or self-propelled crawler tracks – so you can get exactly the configuration that meets your operation.
Komatsu Crushing Joy-underground-feeder-breaker GPL12238 Chain and Flights in white background

Hydraulic conveyor chain tensioning system

Yes, chain tensioning can improve your cycle and uptimes. More accurate tensioning can increase performance and component life. Adjusting take-up without shims or removing covers reduces adjustment time from two hours to two minutes.* *Based on internal testing
Komatsu Crushing Joy-underground-feeder-breaker SFB41 in mining site

Surge capacity control for no waiting

Our unique hopper design helps haulage equipment to discharge material at the maximum rate — eliminating the need for a loader to wait and meter. This can improve cycle times and productivity
Komatsu Crushing Joy-underground-feeder-breaker SFB-32 in mining site

Reduced fines, increased consistency

You can move a variety of material consistencies — wet, dry, sticky or a combination — through a single piece of equipment, as feeder breakers break, instead of crush, materials, reducing fines.

Specifications for SFB-29

Close all Expand all
US system Metric
Typical Applications*

Coal, salt, gypsum, potash, lignite and hard rock materials including copper, gold, pyrite, limestone, and polymetallic materials.

*Larger Surface Feeder breakers are often used to crush softer minerals due to required capacity or feed size.

Coal, salt, gypsum, potash, lignite and hard rock materials including copper, gold, pyrite, limestone, and polymetallic materials.

*Larger Surface Feeder breakers are often used to crush softer minerals due to required capacity or feed size.

Capacity**

Up to 1 500 MTPH

**The rated capacity, maximum mineral compressive strength, and feed size of a Feeder breaker are interdependant.

Up to 1,655 TPH

**The rated capacity, maximum mineral compressive strength, and feed size of a Feeder breaker are interdependant.

Machine Weight
20 - 30 tonnes
22 - 33 tons
Chain Pitch
89.0 mm
3.5 in
Mineral Hardness

Soft and medium

Soft and medium

Maximum Feed Size**

800 mm

**The rated capacity, maximum mineral compressive strength, and feed size of a Feeder breaker are interdependant.

31.5 in

**The rated capacity, maximum mineral compressive strength, and feed size of a Feeder breaker are interdependant.
